High Pressure Reactor

Adopting static seal structure, the stirrer and the motor drive are connected by magnetic coupling, due to its contactless torque transfer, replacing dynamic seal with static seal, it can completely solve the leakage problem of stirring, and make the whole medium and stirring parts work in an absolutely sealed state, therefore, it is more suitable to be used for all kinds of flammable, explosive, poisonous, precious mediums and other chemical mediums with strong penetration. Stirring reaction, is petroleum, chemical, organic synthesis, polymer materials polymerization, food and other processes such as sulfurization, fluoridation, oxidation and other reactions of the most ideal non-leakage reaction equipment.

Get in touch

For technical consultation on our products, specific consultation on solutions and other matters, please fill out the form below and click the “Submit” button. We will contact you as soon as possible.

Please enable JavaScript in your browser to complete this form.
94 People watching this product now!

Product Description

  • Stirring method is optional: Non-stirring, magnetic stirring, paddle stirring
  • Machine type optional: tabletop or vertical
  • Kettle lid lifting optional: Manual or semi-automatic or fully automatic
Mnaual lid liftingVolume LDesign pressure MpaDesign temperature ℃Temperature control accuracy ℃Stirring speed r/minHeating power kwMaterial
GJF-0.050.0522 or 6350±150-10000.61Gr18Ni9Ti
GJF-0.10.10.6
GJF-0.250.250.8
GJF-0.50.51.5
GJF-111.5
GJF-222
GJF-332.5
GJF-5550-6004
GJF-10107



Semi-automatic liftingVolume LDesign pressure MpaDesign temperature ℃Stirring speed r/minHeating power kwHeating method
FCF-0.050.0522 or 635050-10000.6Electric\thermal oil\steam
FCF-0.10.10.6
FCF-0.250.250.8
FCF-0.50.51.5
FCF-111.5
FCF-222



TabletopVolume LDesign pressure MpaDesign temperature ℃Stirring speed r/minHeating power kwHeating method
TGYF-A-0.0250.02522 or 6200/3500-18000.6Electric
TGYF-A-0.050.050.6
TGYF-A-0.10.10.8
TGYF-A-0.20.20.8
TGYF-A-0.250.250.8
TGYF-A-0.50.51.5
1.5
TGYF-A-11
