·Jacket design of feed tank, transfer heating oil preheating and heating preservation function.
·High-precision automatic feeding and discharging pump, with high degree of automation, save labor manpower and working time
·The independent magnetic coupling sealing structure does not affect the vacuum system of the module, ensuring an excellent vacuum effect.
·Standard port connection for supporting heating and refrigeration equipment, easy to match.
·According to the requirements of vacuum degree,it can be matched with different vacuum units to realize two-stage or multi-stage pump connection
| Model | WFE-06S | WFE-1S | WFE-2S | WFE-3S | WFE-5S | WFE-10S | WFE-20S | WFE-50S |
| Feeding rate(L/h) | 1-5 | 2-10 | 2-20 | 2-30 | 10-50 | 20-100 | 40-200 | 100-500 |
| Effective evaporation area(m²) | 0.06 | 0.1 | 0.2 | 0.3 | 0.5 | 1 | 2 | 5 |
| Feeding flask volume(L) | 10 | 15 | 30 | 50 | / | |||
| Vaccum level(mbar) | ≤0.001 | |||||||
| Operation temperature(℃) | ≤350 | |||||||
| Power supply | 220V/50Hz,1P (380V/480V 3P) | |||||||
| Equipment height(mm) | 1800 | 2000 | 2350 | 2650 | 3300 | 4450 | 5000 | 7500 |
